Wattage options: 125 - 500 Watts Dimensions: 122 x 60 x 26 mm
Fe-Cr-Al resistance wire
V: Standard 230 Volts (other voltage values are manufactured upon order)
Effective Wavelength Range: 2-10 microns
Average Operation Time - Up to 20,000 hours depending on conditions.
Recommended application distance - 100 mm to 200 mm
100mm ceramic bead insulated feeding cable
|
HFE Technical Details |
250W |
300W |
400W |
500W |
650W |
750W |
1000W |
|
Average Surface Heat°C |
351 |
405 |
515 |
596 |
640 |
726 |
351 |
|
Max. Operation Temperature°C |
|
750 |
750 |
750 |
750 |
750 |
|
|
Max. Power (kW/m²) |
|
18 |
30 |
39 |
48 |
60 |
|
|
Average Weight |
105 g |
||||||
|
Dimensions |
122 x 60 x 26 mm |
||||||
|
Effective Wavelength |
2 - 10 µm |
||||||
