Wattage options:125 & 250 Watts Dimensions: 60 x 60 x 26mm
Fe-Cr-Al resistance wire
V: Standard 230 Volts (other voltage values are manufactured upon order)
Effective Wavelength Range: 2-10 microns
Average Operation Time - Up to 20,000 hours depending on conditions.
Recommended application distance - 100 mm to 200 mm
100mm ceramic bead insulated feeding cables
Please view our other ceramic infrared resistance products for efficient infrared solutions.
|
QFE Technical Details |
125W |
250W |
|
Average Surface Heat°C |
515 |
726 |
|
Max. surface heat°C |
750 |
|
|
Max. power density (kW/m²) |
|
60 |
|
Average weight |
65g |
|
|
Dimensions |
60 x 60 x 26 mm |
|
|
Effective Wavelength |
2 -10 µm |
|
